Smart Air-Cooled Battery Rack for Renewable Energy Storage Solutions

JNBC768280-V1

产品介绍

This innovative thermal-regulated power storage unit incorporates swappable battery modules and smart climate control technology, delivering stable energy reserves. Boasting exceptional durability with 7000+ charge cycles and simplified servicing, it adapts seamlessly to home, business and factory power needs. Engineered by JNTech's specialists, this system provides an adaptable, economical answer to contemporary energy challenges.

产品特性

Precision Thermal Regulation: Maintains ideal operating conditions to maximize battery efficiency and service duration
Scalable Architecture: Supports incremental power expansion as demand grows
Long-Term Performance: Exceeds 7000 charge cycles under partial discharge conditions
Reduced Ownership Costs: Streamlined upkeep procedures minimize labor expenses

立即咨询

产品手册下载

首页产品储能系统商业与工业 Smart Air-Cooled Battery Rack for Renewable Energy Storage Solutions

技术规格

JNBC768280-V1

Rated capacity	280安时
Rated voltage	768V
Rated energy	215kWh
电池类型	Lithium Iron Phosphate
Max. charging&discharging current	140A
Dimensions(WDH)	115612002240mm
重量	2800Kg
Voltage range	696～864Vdc
工作温度	Charging 0~45 degrees,Discharging -25～55 degrees
存储温度	-20～60 degrees
Communication interface	能
保护级别	IP54
Functional protection	Under-voltage,Over-voltage,Over-current,Temperature,Short circuit
Cycle life	More than 4000 cycles (80%DOD),More than 7000 cycles(70%DOD)
高度	≤3000 m

描述

Power Management
This thermally regulated storage solution delivers consistent energy preservation for photovoltaic installations and decentralized grids. Its configurable battery arrays work in tandem with precision temperature modulation to guarantee peak operation throughout the product lifecycle.

Operational Simplicity
Engineered with maintenance accessibility as a priority, the cabinet’s logical component arrangement and tool-free service points significantly decrease system idle periods while controlling long-term expenditure.

Endurance Specifications
Utilizing advanced battery chemistry, the system withstands 4000 complete discharge cycles while maintaining 80% capacity, with potential lifespan extending beyond 7000 cycles under moderate usage patterns.

Application Flexibility
From household solar storage to commercial peak-shaving and industrial microgrid stabilization, this adaptable power bank meets diverse energy requirements across multiple sectors with a single integrated solution.
